Suzuki 25 HP DF25AES Outboard Motor, 15" Short Shaft, Electric Start

The Suzuki DF25AES is a 25 HP three-cylinder tiller outboard with electric start, battery-less electronic fuel injection and a 15-inch short shaft. Trim and tilt are manual, and the SOHC engine has four valves per cylinder.

The full-throttle range is 5,000-6,000 RPM. Features include Lean Burn Control, Easy Start with recoil starter, digital CDI ignition, an over-rev limiter, a low oil pressure caution, fresh water flushing, a shallow water drive and the Suzuki Anti-Corrosion System. A front-mounted lever selects forward, neutral and reverse.

The motor is water-cooled and saltwater rated, runs on 87-octane unleaded gasoline and uses wet-sump lubrication with SAE 10W-30 or 10W-40 oil. It has no internal battery, a 12V 14A alternator, a 2.09:1 gear ratio and a 3 x 10.25 x 11 propeller. The box holds an owner's manual, aluminum propeller and tool kit.

Highlights

• 25 HP, 3 cylinders, battery-less EFI

• 15-inch short shaft, tiller steering

• Electric start, manual trim and tilt

• Water-cooled and saltwater rated

• 3 x 10.25 x 11 propeller, 2.09:1 gear ratio

• Includes owner's manual, aluminum prop and tool kit

Specifications

Good to know

• Confirm shaft length, controls and propeller rotation against your boat before ordering, and stay within the maximum horsepower on the boat's capacity plate.

• Installation, rigging and commissioning by a qualified marine technician are recommended; follow the manufacturer's pre-delivery and break-in procedures.
